The Graphtec CE6000-60 vinyl cutter sets the standards for high performance cutting plotters.
It features professional level functions including registration mark sensing, SmartFeed™ auto material pre-feed function for enhanced media tracking, and has more punch with its 450gf cutting force.
And as it is a Graphtec you get exceptional build quality and reliability that is all backed up by a 2 year On-Site warranty in Nigeria.
Designed to help you grow your business without a big up-front investment; to deliver professional results to your customers each time, every time.

CE6000 is a 24" (610mm) width vinyl cutter
Increased Cutting Force (450gf)
New ARMS 5.0 System For Improved Print & Cut
Reliable Long Length Tracking
Large LCD Display
Includes New Graphtec Pro Studio & Cutting Master 4 Software
Floor Stand & Media Rollers
Intuitive & Easy To Use
2 Year On-Site Warranty
Plug-ins included for Corel Draw & Adobe Illustrator

A max force of 4.41 N (450 gf),
speed of 1000 mm/s

With maximum force of the 4.41 N (450 gf) and a maximum speed of 1000 mm/s, it enable to cut various media with high productivity.



Reliable long length tracking up to 5 m long

Its media stocker ensures a more stable media feed as up to 5 m.
The long size of cutting object is able to cut accurate and stable using the automatic paneling function.


Support various media

It enable to support wide range of media including self-adhesive vinyl film for signs, self-adhesive printable film/paper media for labels/stickers, and thick paper for POP as the table advertising






Specification-

CPU - 32-bit CPU
Configuration - Grit-rolling friction feed
Drive - Digital Servo Drive
Maximum cutting area - 603 mm x 50 m [23.7" x 164']
Range of guaranteed precision - 584 x 2 m
584 x 5 m when using optional basket
Compatible media widths - Minimum: 50 mm [2"]
Maximum: 712 mm [28"]
Maximum media thickness - 0.25 mm [10 mils]
Maximum cutting speed - 90 cm/s (at 45° direction)
Maximum acceleration - 21.2 m/s² (at 45° direction)
Maximum guaranteed cutting force - 4.41N (450 gf) in 38 steps
Minimum character matrix - Approx 5 mm [0.2"] high
Film types - Self-adhesive vinyl film, fluorescent film, commercial grade reflective film, polyester film.
Interfaces - RS-232C serial, USB2 (Full Speed)
Data buffer - 2 MB
Command sets - GP-GL™ / HP-GL® emulation (control panel selectable)
Registration mark sensing - Optical sensor ARMS5.0
Power requirements - 100 to 120 VAC, 220 to 240 V AC (Auto Switch), 50/60 Hz
Operating environment - 10 to 35°C [50 to 95°F], 35 to 75% RH (non-condensing)
External Dimensions - 900x593x106mm
Certifications - CE Mark; CUL, VCC Class A, FCC Class A, EN55022 Class A
